Automatic MPX1150 Painting Robot Arm 5KG Welding 6 Axis

Ask Lasest Price
Brand Name :	Fanuc
Model Number :	New Product 2020
Certification :	CE
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	999 sets/month
Delivery Time :	6-8 weeks

Add to Cart

Product Details
Company Profile

Automatic MPX1150 Painting Robot Arm 5KG Welding 6 Axis

Automatic Painting Robot MPX1150 Compact Payload 5kg With 6 Robotic Arm Painting As Painting Robot

The compact MOTOMAN MPX1150 robot was developed especially for painting of small workpieces. It provides a payload of 5 kg for mounting multiple guns and small bell models. Teh very compact design helps keeping the size of the paint booth small. The S/L axis is designed with no offset to enable installation of the manipulator closer to a work piece. The robot can be mounted on the floor, wall or ceiling and has three selectable access points for power cables.

Description:

item	value
Type	Coating Production Line
Machine Type	Robot arm
Video outgoing-inspection	Provided
Machinery Test Report	Provided
Marketing Type	New Product 2020
Warranty of core components	1 Year
Core Components	Engine, Motor
Place of Origin	China
Brand Name	Yaskawa
Warranty	1 Year
Key Selling Points	Easy to Operate
Applicable Industries	Building Material Shops, Machinery Repair Shops, Printing Shops, Energy & Mining, Other
Showroom Location	Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Mexico, Spain, Chile, Australia
Weight (KG)	57
Machine Type	Painting Equipment
Brand	Yaskawa
Model	MPX1150
Axis	6 axis
Payload	5 kg
Reach	727 mm
Controller	DX200-FM
Repeatability	±0.02 mm
Maximum speed	1.5 m/s
Brakes	All axes
Power consumption	1 kVA

Adwantage:

Ideal for painting smaller components, the compact MPX1150 robot has a straight wrist with 5 kg payload capacity. It is well-suited for mounting a variety of spray guns and small bells. Its small footprint and slim arm design allow for minimum installation space. An optional location (right, left or bottom) for manipulator cable connection reduces interference with walls. The MPX1150 robot features a 727 mm horizontal reach, 1,290 mm vertical reach and ±0.02 mm repeatability.

The MPX1150 robots offer reduced interference work envelopes and can be installed close to workpieces for efficient use of floorspace. Each robot can be floor-, wall- or ceiling-mounted for layout flexibility.

The MPX1150 robot features Factory Mutual (FM) approval for use in Class I, Division 1 hazardous environments. An intrinsically safe pendant is available as an option.

With a large global install base, backed by Yaskawa’s experience and reliability, the MPX-series line of robots offers exceptional performance with proven efficiency.

Our service:

1.Swift delivery
For common parts, we can deliver the goods within 3 days

2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3.Quality Assurance

4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.

5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.

Application:

dispensing, finishing, material handling, pick and place, assembly, palletizing, 3d printing, and remote tcp.
